Simrad 6 feet Antenna for Halo

ANTENNA, RADAR, HALO, 6FT

Simrad Forward Looking Transducer kit Model: 000-11674-001

• Provides water depth information in front of the boat to allow boaters to confidently navigate shallow or poorly charted waters
• Look ahead view is capable of up to 8 times the depth however the normal operating range is 4 to 5 times the depth. Ex 10 feet depth would provide a 80 feet forward view
• Operates at 180kHz to reduce interference from tradition 200kHz echo sounders.Transmits and receives up to ten times faster than previous forward looking systems providing a real time update.
• Network Options: Connect directly to Sonar Hub or NSS evo2. ForwardScan Sonar view available on the following displays NSS Evo2, NSO Evo2, Zeus 2

ForwardScanTM Sonar is the ideal forward looking two dimensional echo-sounder for all power and sail boats that want safety and peace of mind that comes with knowing the depth of the water ahead of the boat. Unlike other Forward-looking sounders, the ForwardScan can display bottom imagery up to 8 times the current depth, it integrates with your onboard NS evo2 or Zeus Touch providing full control at any operating station

Simrad NAC-1 Course Computer

NAC-1 Autopilot Computer - The brains behind the Outboard Pilot and Drive Pilot systems. It contains the steering computer and electronics for the drive unit motor and clutch.

• NAC-1
• Power cord

Simrad 3 feet Antenna for Halo

• Advanced signal processing: Halo Radar employs advanced signal processing for digital azimuth and range sidelobe reduction, enhancing discrimination of small targets such as channel markers from larger adjacent targets such as ships and bridges. In addition, Directional Sea Clutter Rejection dynamically changes gain in the sweep to allow smaller targets to be seen in the leeward. Coming soon via free NSS/NSO evo2 software update, Sector Blanking reduces on-screen clutter by eliminating unwanted reflections in up to four user-defined zones.
• Halo Pulse Compression Radar provides rapid position updates, with high speed operation up to 48RPM (mode and range dependent). Simrad quality construction and Halo Radar’s brushless motor with advanced helical geartrain design ensure exceptionally quiet operation, especially at 48RPM.
• Collision hazards won’t wait for your radar to start up - why should you? Halo Radar’s solid-state technology is ready instantly from standby, and in just 16-25 seconds from power-on to fully-operational. Avoid the 2-3 minute warm-up time associated with traditional pulse radar, and trust Halo Radar to produce an immediate, accurate radar image when you need it.
• Track up to 10 user-selected radar targets, displaying CPA (closest point of approach) and TCPA (time to closest point of approach). Up to 20 different targets can be tracked in Dual Range mode, with 10 targets per screen. MARPA functionality requires a heading sensor and GPS.
• Unlike traditional pulse radar, Halo Radar transmits low-power pulses. This makes Halo Radar safe to run in anchorages and marinas, providing enhanced radar coverage at the very start and end of each journey. In fact, Halo Radar’s minimum safe distance in any transmission mode is within the swing circle of its open array antenna
• Halo Radar uses 40W average with no wind, and no more than 150W at maximum wind velocity. Experience even greater power savings in standby with just 6.5W power usage, versus 10-15W for pulse radar. With its low power consumption and support for 12/24 volt DC systems, Halo Radar is ideal for small to mid-sized powerboats
• Halo Pulse Compression Radar connects to any Simrad NSS evo2 or NSO evo2 multi-function display system via Ethernet, with a bulkhead-mounted interface box below deck. Antenna installation is simple and elegant.
• Unique soft-glow, dual-beam Blue LED accent lighting, integrated into the pedestal and customizable with 4-level brightness control

Combining the best characteristics of traditional pulse and Frequency Modulated Continuous Wave broadband radar systems, Simrad HaloTM Radar uses Pulse Compression technology to provide an unprecedented mix of long and short detection range, high target definition and minimal clutter in an affordable package.

Solid state technology means minimal warm-up time and maximum ocean-going reliability, while low RF emissions make HaloTM Radar safe to install in a wider range of onboard locations.

Beam Sharpening technology delivers a more detailed picture, with improved separation of adjacent targets.

• Automatic Harbor
• Offshore
• Weather and BIRD modes
• Custom manual mode
• MARPA
• Dual Range
• InstantON
• Low power draw
• Low electromagnetic emission

Simrad 4 feet Antenna for Halo

ANTENNA, RADAR, HALO, 4FT

Simrad PUMP-1 MKII Hydraulic Pump - 0.8L 12v

Reversible hydraulic pump, compatible with SeaStar manual helm pumps up to 14ci. Includes 3 x ORB-5 to 9/16 UNF fittings.

• Pump-1 MkII
• 3 x ORB-5 to 9/16 UNF fittings

Simrad A2004 Autpilot Control Head

• Proven Simrad interface designed for commercial marine applications
• Large, heavy-duty rotary control dial for precision steering
• Continuum steering technology
• Optically bonded 4.1-inch colour display with 170 deg viewing angle
• Thruster integration & heavy-duty rudder feedback support
• Configurable work mode and low/high speed modes
• Automated turn patterns for fuel-efficient, hands-free manoeuvres
• No Drift steering holds course against wind and tide
• Flush or bracket mounting options
• Certified NMEA 2000(R) connectivity

The A2004 is a dedicated autopilot controller designed to meet the needs of professional mariners aboard a variety of commercial vessels. It features a proven Simrad interface, presented on a wide-angle and zero-fog colour display. Engineered for responsiveness and ease of use, the A2004 pairs a precision rotary control dial with dedicated buttons for instant access to steering modes, a custom-configurable Work mode, and automated turn patterns.

The A2004 builds upon the proven user interface and keypad layout of the Simrad AP70 and AP80 professional autopilot controllers, and delivers consistency with the latest generation of Simrad radar, sonar, and ECDIS displays.A large aluminium rotary control dial enables quick but precise steering adjustments, while dedicated keys offer instant access to steering modes, a custom-configurable Work mode, and automated turn patterns. All built-in controls are designed for ease of use with wet or gloved hands, in commercial settings such as fishing vessels and workboats. The A2004 also supports a wide range of Simrad autopilot remotes and steering levers.

Every Simrad steering innovation builds upon a legacy encompassing over sixty years of autopilot development, which continues to this day. This legacy is exemplified by the Continuum algorithm: the software behind Simrad steering technology. Continuum steering distils years of research and on-water testing into a flexible software solution, capable of delivering reliable auto-steering performance tuned specifically to match a vessel’s control characteristics. With a comprehensive range of hardware and interface modules, Simrad autopilot solutions can be tailored to suit a wide range of commercial vessels and applications.

To ensure optimal visibility in all conditions, the A2004’s colour LCD panel is optically bonded to its protective glass covering - eliminating the possibility of internal condensation. Transflective LCD technology makes use of reflected sunlight to brighten rather than obscure the screen, delivering superior day-time visibility and lower power consumption compared to traditional backlit displays. An ultra-wide 170 degree viewing angle means key autopilot information is clearly visible at a glance, from anywhere in sight of the display.

The A2004 enables autopilot control of a single thruster via an optional AD80 or SD80 interface module. The thruster can be set to engage automatically below a user-defined speed threshold, and configured separately for normal and Work modes. The A2004 also supports specialized heavy-duty rudder feedback units designed for reliable operation aboard commercial vessels.

• A2004 Control
• Mounting Bracket
• Dash Mount

Simrad NSS evo3S 9in Display

• High Resolution, High Bright, SolarMax IPS Displays
• Easy to use touchscreen UI as well as full keypad for simple and precise control in any sea conditions
• Built-in advanced echosounder capable of 1kW Dual channel CHIRP, Forwardscan, Sidescan, Downscan and StructureScan 3D images
• Take another step forward with Simrad’s premium network modules for the ultimate offshore performance
• Halo Dome and Open Array Radars: S5100 Sportfishing Echosounder, Direct audio, autopilot and engine connection and control
• Low profile glass dash styling
• Built in Wi-Fi connectivity
• Next Generation Processor
• SolarMAX IPS Display Technology
• Multi-touch screen and keypad hybrid control
• Built-in Advanced Echosounder

NSS evo3S is a mid-life update to the NSS evo3. The key difference is a next generation processor. This greatly improves the speed and smoothness of the display. The NSS evo3 is already a feature packed product and the new processor in the evo3S means that each one of those features is now improved

Simrad NSS evo3S 12in Display

• High Resolution, High Bright, SolarMax IPS Displays
• Easy to use touchscreen UI as well as full keypad for simple and precise control in any sea conditions
• Built-in advanced echosounder capable of 1kW Dual channel CHIRP, Forwardscan, Sidescan, Downscan and StructureScan 3D images
• Take another step forward with Simrad’s premium network modules for the ultimate offshore performance
• Halo Dome and Open Array Radars: S5100 Sportfishing Echosounder, Direct audio, autopilot and engine connection and control
• Low profile glass dash styling
• Built in Wi-Fi connectivity
• Next Generation Processor
• SolarMAX IPS Display Technology
• Multi-touch screen and keypad hybrid control
• Built-in Advanced Echosounder

NSS evo3S is a mid-life update to the NSS evo3. The key difference is a next generation processor. This greatly improves the speed and smoothness of the display. The NSS evo3 is already a feature packed product and the new processor in the evo3S means that each one of those features is now improved

Simrad NSX 3007 - Smart Chartplotter / fishfinder. HDI Skimmer med/high 455/800 kHz transducer. Next-generation C-MAP(R) DISCOVERTM X chart

• Features support for the new marine-optimized C-MAP(R) DISCOVERTM X and C-MAP REVEALTM X charts with a fresh, intuitive chart presentation and daily updates
• High-definition IPS touch screen with extreme viewing angles, viewable through polarized lenses
• Support for high-resolution views of fish and structure with Active ImagingTM featuring CHIRP, SideScan and DownScan ImagingTM, plus 1kW transducer capability to reach greater depths
• Quickly identify fish with FishRevealTM
• Setup Wizard to get you up and running quickly, plus simpler sonar setup
• Full integration with the capability to expand the system with Simrad(R) radar, autopilot, and more
• Faster Autorouting with seamless accessibility
• Stay on course with full Simrad(R) autopilot integration
• Modern and straightforward interface
• Simrad(R) App integration - keep your chart data at your fingertips, both on and off the water
• Third-party app integration
• Wireless connectivity, plus Ethernet and NMEA 2000(R) networking capability
• IP Video Support

Experience modern simplicity in rich detail. NSX pairs a clean and straightforward interface with high-definition visuals to deliver a whole new experience. Easily access and use all NSX features, including smart drag-and-drop screen customization, fully editable instruments bar and enhanced day and night modes. Get crystal clear views of chart detail, structure and bottom contours with the vibrant SolarMAXTM IPS touch screen. The high-definition display is viewable from any angle, in direct sunlight, and through polarized lenses with complete touch screen operation.

See map details in a new way with a next-generation C-MAP(R) DISCOVER XTM marine-optimized charts developed for NSX, featuring a fresh, intuitive chart presentation and daily updates. NSX also supports marine-optimized C-MAP Reveal X charts with coastal, seafloor and inland Shaded Relief. C-MAP charts include full-featured Vector Charts with Custom Depth Shading and High-Resolution Bathymetry showing accurate contour lines down to a 1-foot level of detail. You can improve planning and route plotting with Tides and Currents projections and our fastest ever Autorouting. Plus, there’s a new Map Inspection feature with one-touch access to information on locations, POIs, tides, channels and more. The Simrad(R) Companion App acts like an extension of your NSX with the same chart experiences and all your chart data at your fingertips, on or off the water. The app lets you plan trips, review Tracks and plot Waypoints on your App and sync directly to your NSX.

NSX opens up a world of possibilities, from the included Active ImagingTM 3-in-1 transducer with CHIRP sonar, SideScan and DownScan ImagingTM to system expansion options like Autopilot and a wide range of compatible 1kW transducers that allow you to search greater depths. Identify hazards immediately with our award-winning pulse compression HALO Radars. See near and far simultaneously (up to 72 nm) and be ready instantly with low-power standby mode. Highlight targets using custom modes such as harbor, offshore and weather. Known for its legendary performance, Simrad(R) Autopilots free you up to enjoy all of your activities. Whether trawling for game fish or planning your next destination, we’ve got you covered. Available for outboard and inboard engines, our ’extra pair of hands’ helps run patterns and routes, navigate to waypoints, and stay on course.

With everything from a Setup Wizard to Simrad(R) App integration, simple sonar setup and hints to assist you when you need it, NSX makes life on the water easier than ever before. The Setup Wizard helps with step-by-step instructions to get you up and running quickly, while the Simrad(R) App offers a whole host of added extras. These include hassle-free software updates, on and off the water trip planning, a streamlined chart display that looks the same across all platforms, plus easy transfer of all data, including routes and waypoints. But that’s not all. Sonar hints offer guidance on what’s happening during settings adjustments and sonar device setup gives you easy-to-understand prompts for each step of the process - you’ll be up and running in no time. All you need to do now is choose your next adventure.

Simrad NSX 3009 - Smart Chartplotter / fishfinder. HDI Skimmer med/high 455/800 kHz transducer. C-MAP(R) DISCOVERTM X chart included

• Features support for the new marine-optimized C-MAP(R) DISCOVERTM X and C-MAP REVEALTM X charts with a fresh, intuitive chart presentation and daily updates
• High-definition IPS touch screen with extreme viewing angles, viewable through polarized lenses
• Support for high-resolution views of fish and structure with Active ImagingTM featuring CHIRP, SideScan and DownScan ImagingTM, plus 1kW transducer capability to reach greater depths
• Quickly identify fish with FishRevealTM
• Setup Wizard to get you up and running quickly, plus simpler sonar setup
• Full integration with the capability to expand the system with Simrad(R) radar, autopilot, and more
• Faster Autorouting with seamless accessibility
• Stay on course with full Simrad(R) autopilot integration
• Modern and straightforward interface
• Simrad(R) App integration - keep your chart data at your fingertips, both on and off the water
• Third-party app integration
• Wireless connectivity, plus Ethernet and NMEA 2000(R) networking capability
• IP Video Support

Experience modern simplicity in rich detail. NSX pairs a clean and straightforward interface with high-definition visuals to deliver a whole new experience. Easily access and use all NSX features, including smart drag-and-drop screen customization, fully editable instruments bar and enhanced day and night modes. Get crystal clear views of chart detail, structure and bottom contours with the vibrant SolarMAXTM IPS touch screen. The high-definition display is viewable from any angle, in direct sunlight, and through polarized lenses with complete touch screen operation.

See map details in a new way with a next-generation C-MAP(R) DISCOVER XTM marine-optimized charts developed for NSX, featuring a fresh, intuitive chart presentation and daily updates. NSX also supports marine-optimized C-MAP Reveal X charts with coastal, seafloor and inland Shaded Relief. C-MAP charts include full-featured Vector Charts with Custom Depth Shading and High-Resolution Bathymetry showing accurate contour lines down to a 1-foot level of detail. You can improve planning and route plotting with Tides and Currents projections and our fastest ever Autorouting. Plus, there’s a new Map Inspection feature with one-touch access to information on locations, POIs, tides, channels and more. The Simrad(R) Companion App acts like an extension of your NSX with the same chart experiences and all your chart data at your fingertips, on or off the water. The app lets you plan trips, review Tracks and plot Waypoints on your App and sync directly to your NSX.

NSX opens up a world of possibilities, from the included Active ImagingTM 3-in-1 transducer with CHIRP sonar, SideScan and DownScan ImagingTM to system expansion options like Autopilot and a wide range of compatible 1kW transducers that allow you to search greater depths. Identify hazards immediately with our award-winning pulse compression HALO Radars. See near and far simultaneously (up to 72 nm) and be ready instantly with low-power standby mode. Highlight targets using custom modes such as harbor, offshore and weather. Known for its legendary performance, Simrad(R) Autopilots free you up to enjoy all of your activities. Whether trawling for game fish or planning your next destination, we’ve got you covered. Available for outboard and inboard engines, our ’extra pair of hands’ helps run patterns and routes, navigate to waypoints, and stay on course.

With everything from a Setup Wizard to Simrad(R) App integration, simple sonar setup and hints to assist you when you need it, NSX makes life on the water easier than ever before. The Setup Wizard helps with step-by-step instructions to get you up and running quickly, while the Simrad(R) App offers a whole host of added extras. These include hassle-free software updates, on and off the water trip planning, a streamlined chart display that looks the same across all platforms, plus easy transfer of all data, including routes and waypoints. But that’s not all. Sonar hints offer guidance on what’s happening during settings adjustments and sonar device setup gives you easy-to-understand prompts for each step of the process - you’ll be up and running in no time. All you need to do now is choose your next adventure.

Simrad NSX 3009 - Smart Chartplotter / fishfinder Radar Bundle. Active ImagingTM 3-in-1 transducer. C-MAP(R) DISCOVERTM X chart and Halo 20+ Radar included

• Features support for the new marine-optimized C-MAP(R) DISCOVERTM X and C-MAP REVEALTM X charts with a fresh, intuitive chart presentation and daily updates
• High-definition IPS touch screen with extreme viewing angles, viewable through polarized lenses
• Support for high-resolution views of fish and structure with Active ImagingTM featuring CHIRP, SideScan and DownScan ImagingTM, plus 1kW transducer capability to reach greater depths
• Quickly identify fish with FishRevealTM
• Setup Wizard to get you up and running quickly, plus simpler sonar setup
• Full integration with the capability to expand the system with Simrad(R) radar, autopilot, and more
• Faster Autorouting with seamless accessibility
• Stay on course with full Simrad(R) autopilot integration
• Modern and straightforward interface
• Simrad(R) App integration - keep your chart data at your fingertips, both on and off the water
• Third-party app integration
• Wireless connectivity, plus Ethernet and NMEA 2000(R) networking capability
• IP Video Support

Experience modern simplicity in rich detail. NSX pairs a clean and straightforward interface with high-definition visuals to deliver a whole new experience. Easily access and use all NSX features, including smart drag-and-drop screen customization, fully editable instruments bar and enhanced day and night modes. Get crystal clear views of chart detail, structure and bottom contours with the vibrant SolarMAXTM IPS touch screen. The high-definition display is viewable from any angle, in direct sunlight, and through polarized lenses with complete touch screen operation.

See map details in a new way with a next-generation C-MAP(R) DISCOVER XTM marine-optimized charts developed for NSX, featuring a fresh, intuitive chart presentation and daily updates. NSX also supports marine-optimized C-MAP Reveal X charts with coastal, seafloor and inland Shaded Relief. C-MAP charts include full-featured Vector Charts with Custom Depth Shading and High-Resolution Bathymetry showing accurate contour lines down to a 1-foot level of detail. You can improve planning and route plotting with Tides and Currents projections and our fastest ever Autorouting. Plus, there’s a new Map Inspection feature with one-touch access to information on locations, POIs, tides, channels and more. The Simrad(R) Companion App acts like an extension of your NSX with the same chart experiences and all your chart data at your fingertips, on or off the water. The app lets you plan trips, review Tracks and plot Waypoints on your App and sync directly to your NSX.

NSX opens up a world of possibilities, from the included Active ImagingTM 3-in-1 transducer with CHIRP sonar, SideScan and DownScan ImagingTM to system expansion options like Autopilot and a wide range of compatible 1kW transducers that allow you to search greater depths. Identify hazards immediately with our award-winning pulse compression HALO Radars. See near and far simultaneously (up to 72 nm) and be ready instantly with low-power standby mode. Highlight targets using custom modes such as harbor, offshore and weather. Known for its legendary performance, Simrad(R) Autopilots free you up to enjoy all of your activities. Whether trawling for game fish or planning your next destination, we’ve got you covered. Available for outboard and inboard engines, our ’extra pair of hands’ helps run patterns and routes, navigate to waypoints, and stay on course.

With everything from a Setup Wizard to Simrad(R) App integration, simple sonar setup and hints to assist you when you need it, NSX makes life on the water easier than ever before. The Setup Wizard helps with step-by-step instructions to get you up and running quickly, while the Simrad(R) App offers a whole host of added extras. These include hassle-free software updates, on and off the water trip planning, a streamlined chart display that looks the same across all platforms, plus easy transfer of all data, including routes and waypoints. But that’s not all. Sonar hints offer guidance on what’s happening during settings adjustments and sonar device setup gives you easy-to-understand prompts for each step of the process - you’ll be up and running in no time. All you need to do now is choose your next adventure.

Simrad NSX 3012 - Smart Chartplotter / fishfinder. Active Imaging 3-in-1 transducer. C-MAP(R) DISCOVERTM X chart and Halo 20+ Radar included

• Features support for the new marine-optimized C-MAP(R) DISCOVERTM X and C-MAP REVEALTM X charts with a fresh, intuitive chart presentation and daily updates
• High-definition IPS touch screen with extreme viewing angles, viewable through polarized lenses
• Support for high-resolution views of fish and structure with Active ImagingTM featuring CHIRP, SideScan and DownScan ImagingTM, plus 1kW transducer capability to reach greater depths
• Quickly identify fish with FishRevealTM
• Setup Wizard to get you up and running quickly, plus simpler sonar setup
• Full integration with the capability to expand the system with Simrad(R) radar, autopilot, and more
• Faster Autorouting with seamless accessibility
• Stay on course with full Simrad(R) autopilot integration
• Modern and straightforward interface
• Simrad(R) App integration - keep your chart data at your fingertips, both on and off the water
• Third-party app integration
• Wireless connectivity, plus Ethernet and NMEA 2000(R) networking capability
• IP Video Support

Experience modern simplicity in rich detail. NSX pairs a clean and straightforward interface with high-definition visuals to deliver a whole new experience. Easily access and use all NSX features, including smart drag-and-drop screen customization, fully editable instruments bar and enhanced day and night modes. Get crystal clear views of chart detail, structure and bottom contours with the vibrant SolarMAXTM IPS touch screen. The high-definition display is viewable from any angle, in direct sunlight, and through polarized lenses with complete touch screen operation.

See map details in a new way with a next-generation C-MAP(R) DISCOVER XTM marine-optimized charts developed for NSX, featuring a fresh, intuitive chart presentation and daily updates. NSX also supports marine-optimized C-MAP Reveal X charts with coastal, seafloor and inland Shaded Relief. C-MAP charts include full-featured Vector Charts with Custom Depth Shading and High-Resolution Bathymetry showing accurate contour lines down to a 1-foot level of detail. You can improve planning and route plotting with Tides and Currents projections and our fastest ever Autorouting. Plus, there’s a new Map Inspection feature with one-touch access to information on locations, POIs, tides, channels and more. The Simrad(R) Companion App acts like an extension of your NSX with the same chart experiences and all your chart data at your fingertips, on or off the water. The app lets you plan trips, review Tracks and plot Waypoints on your App and sync directly to your NSX.

NSX opens up a world of possibilities, from the included Active ImagingTM 3-in-1 transducer with CHIRP sonar, SideScan and DownScan ImagingTM to system expansion options like Autopilot and a wide range of compatible 1kW transducers that allow you to search greater depths. Identify hazards immediately with our award-winning pulse compression HALO Radars. See near and far simultaneously (up to 72 nm) and be ready instantly with low-power standby mode. Highlight targets using custom modes such as harbor, offshore and weather. Known for its legendary performance, Simrad(R) Autopilots free you up to enjoy all of your activities. Whether trawling for game fish or planning your next destination, we’ve got you covered. Available for outboard and inboard engines, our ’extra pair of hands’ helps run patterns and routes, navigate to waypoints, and stay on course.

With everything from a Setup Wizard to Simrad(R) App integration, simple sonar setup and hints to assist you when you need it, NSX makes life on the water easier than ever before. The Setup Wizard helps with step-by-step instructions to get you up and running quickly, while the Simrad(R) App offers a whole host of added extras. These include hassle-free software updates, on and off the water trip planning, a streamlined chart display that looks the same across all platforms, plus easy transfer of all data, including routes and waypoints. But that’s not all. Sonar hints offer guidance on what’s happening during settings adjustments and sonar device setup gives you easy-to-understand prompts for each step of the process - you’ll be up and running in no time. All you need to do now is choose your next adventure.

• Waterproof sealing for protection of the elements and reliable use
• Extremely quiet, enjoy the silence of sailing
• SimNet compatible, simple plug and play DIY installation (TP22 and TP32)
• Easy operation

TP10 - Yachts up to 33ft
TP22 - Yachts up to 36ft
TP32 - Yachts up to 39ft High performance for small to mid range sailboats Simrad Tillerpilots are designed for high precision, reliable autosteering while drawing low current to optimize battery life. The hard wearing, waterproof body contains all controls and has been tested for many hours in total immersion. Exceptionally quiet in use, the Tillerpilot gives fast and positive performance for effective steering in a wide range of sea states and wind conditions. A range of pilots offers performance to suit most small to medium sailboats.

The TP22 and TP32 pilots offer easy interfacing to external devices using Simrad’s proprietary network system, SimNet. When interfaced, enhanced options such as sail to wind or sail to waypoint are easily accessed via the key pad. The recommendations assume typical coastal sailing conditions and in circumstances where extended voyages or more extreme weather conditions are expected, the choice of a higher specification pilot is recommended including the full range of Simrad below deck pilots.

• Waterproof sealing for protection of the elements and reliable use
• Extremely quiet, enjoy the silence of sailing
• SimNet compatible, simple plug and play DIY installation (TP22 and TP32)
• Easy operation

TP10 - Yachts up to 33ft
TP22 - Yachts up to 36ft
TP32 - Yachts up to 39ft High performance for small to mid range sailboats Simrad Tillerpilots are designed for high precision, reliable autosteering while drawing low current to optimize battery life. The hard wearing, waterproof body contains all controls and has been tested for many hours in total immersion. Exceptionally quiet in use, the Tillerpilot gives fast and positive performance for effective steering in a wide range of sea states and wind conditions. A range of pilots offers performance to suit most small to medium sailboats.

The TP22 and TP32 pilots offer easy interfacing to external devices using Simrad’s proprietary network system, SimNet. When interfaced, enhanced options such as sail to wind or sail to waypoint are easily accessed via the key pad. The recommendations assume typical coastal sailing conditions and in circumstances where extended voyages or more extreme weather conditions are expected, the choice of a higher specification pilot is recommended including the full range of Simrad below deck pilots.

Simrad WR10 Wireless Autopilot remote and Base station

• Easy to use, simple DIY install
• Heading control/dodge in 1 deg and 10 deg increments
• Dedicated autopilot standby & engage buttons
• Quickly toggle autopilot/NoDrift steering
• Multicolour status LED with low battery indication
• Compact, lightweight remote
• Wristband or lanyard attachment
• Up to 30m range
• Waterproof base station, deck or pole mount
• NMEA 2000(R) connection (Micro-C)

Stay in control, wherever you are on board. Incorporating long-range Bluetooth technology for up to 30 metres range in a compact and lightweight package, the WR10 wireless remote works with Simrad autopilot systems to enable precise heading adjustments and autopilot control.

The WR10 is compatible with Simrad AC12, AC42, NAC-1, NAC-2, NAC-3 and SG05 autopilot systems, and makes the perfect wireless companion to your dedicated autopilot head unit, OP40 wired remote, or NSS/NSO multifunction displays.

The WR10 offers a simple do-it-yourself upgrade to any autopilot system based on the Simrad AC12, AC42, NAC-1, NAC-2, NAC-3 and SG05 autopilot computer. The included BT1 Bluetooth base station quickly connects to your boat’s NMEA 2000(R) network with its plug-and-play Micro-C connector: there’s no need for any complex wiring, or an external power supply. The compact and waterproof BT1 may be either deck or pole mounted, offers up to 30m range, and can be paired with up to four WR10 remotes

• Blue tooth module
• WR10 remote
• lanyard

Simrad OP50 Wired Remote Control, Portrait Mount

• Control up to 6 MFD displays
• Functions with NSS evo2/3 all sizes, NSO evo2/3 and GO7
• Keypad configuration is optimized for Simrad HEROiC software control
• Aluminium control dial with build in cursor functions
• High volume alarm output for critical notifications
• Single NMEA2000 connection

OP50 features a single control dial that provides multi axis controls Rotary selector for menu select, chart zoom etc. X,Y cursor pad for chart panning and cursor placement Push to select enter key

Simrad Precision 9 Compass

• Heading, Rate Of Turn (ROT), roll, and pitch output over NMEA 2000(R)
• Heading and ROT calculated using sensor data from 9 axes of rotation and motion
• Accurate and reliable solid-state sensor technology
• Heading accuracy of ±2 deg after calibration
• Easily adjustable mounting bracket allows bulkhead or up-mast installation
• IPX7 waterproof. Best in class.
• Simple installation with a single NMEA 2000(R) connection

The Precision-9 Compass supplies heading and rate-of-turn information to Simrad, B&G and Lowrance autopilot, radar and navigation systems. Based on reliable solid-state sensor technology, this compact compass offers easy installation aboard any vessel.

• Precision 9 Compass
• N2K-T-RD - Micro-C T-connector
• N2KEXT-15RD - 4.55 m (15-ft) NMEA 2000(R) cable

Simrad A2004 Autpilot Pack

• Proven Simrad interface designed for commercial marine applications
• Large, heavy-duty rotary control dial for precision steering
• Continuum steering technology
• Optically bonded 4.1-inch colour display with 170 deg viewing angle
• Thruster integration & heavy-duty rudder feedback support
• Configurable work mode and low/high speed modes
• Automated turn patterns for fuel-efficient, hands-free manoeuvres
• No Drift steering holds course against wind and tide
• Flush or bracket mounting options
• Certified NMEA 2000(R) connectivity

The A2004 is a dedicated autopilot controller designed to meet the needs of professional mariners aboard a variety of commercial vessels. It features a proven Simrad interface, presented on a wide-angle and zero-fog colour display. Engineered for responsiveness and ease of use, the A2004 pairs a precision rotary control dial with dedicated buttons for instant access to steering modes, a custom-configurable Work mode, and automated turn patterns.

The A2004 builds upon the proven user interface and keypad layout of the Simrad AP70 and AP80 professional autopilot controllers, and delivers consistency with the latest generation of Simrad radar, sonar, and ECDIS displays.A large aluminium rotary control dial enables quick but precise steering adjustments, while dedicated keys offer instant access to steering modes, a custom-configurable Work mode, and automated turn patterns. All built-in controls are designed for ease of use with wet or gloved hands, in commercial settings such as fishing vessels and workboats. The A2004 also supports a wide range of Simrad autopilot remotes and steering levers.

Every Simrad steering innovation builds upon a legacy encompassing over sixty years of autopilot development, which continues to this day. This legacy is exemplified by the Continuum algorithm: the software behind Simrad steering technology. Continuum steering distils years of research and on-water testing into a flexible software solution, capable of delivering reliable auto-steering performance tuned specifically to match a vessel’s control characteristics. With a comprehensive range of hardware and interface modules, Simrad autopilot solutions can be tailored to suit a wide range of commercial vessels and applications.

To ensure optimal visibility in all conditions, the A2004’s colour LCD panel is optically bonded to its protective glass covering - eliminating the possibility of internal condensation. Transflective LCD technology makes use of reflected sunlight to brighten rather than obscure the screen, delivering superior day-time visibility and lower power consumption compared to traditional backlit displays. An ultra-wide 170 degree viewing angle means key autopilot information is clearly visible at a glance, from anywhere in sight of the display.

The A2004 enables autopilot control of a single thruster via an optional AD80 or SD80 interface module. The thruster can be set to engage automatically below a user-defined speed threshold, and configured separately for normal and Work modes. The A2004 also supports specialized heavy-duty rudder feedback units designed for reliable operation aboard commercial vessels.

• A2004 Control
• AC70 Computer
• RF300 Feedback

Simrad NSS evo3S 16in Display

• High Resolution, High Bright, SolarMax IPS Displays
• Easy to use touchscreen UI as well as full keypad for simple and precise control in any sea conditions
• Built-in advanced echosounder capable of 1kW Dual channel CHIRP, Forwardscan, Sidescan, Downscan and StructureScan 3D images
• Take another step forward with Simrad’s premium network modules for the ultimate offshore performance
• Halo Dome and Open Array Radars: S5100 Sportfishing Echosounder, Direct audio, autopilot and engine connection and control
• Low profile glass dash styling
• Built in Wi-Fi connectivity
• Next Generation Processor
• SolarMAX IPS Display Technology
• Multi-touch screen and keypad hybrid control
• Built-in Advanced Echosounder

NSS evo3S is a mid-life update to the NSS evo3. The key difference is a next generation processor. This greatly improves the speed and smoothness of the display. The NSS evo3 is already a feature packed product and the new processor in the evo3S means that each one of those features is now improved

Simrad PUMP-2 12v 0.8L Hydraulic Pumpset, SteadySteer Compatible

• Reversible gear pump
• Moderate Flow Rate
• 12V DC
• 80-250 cc (4.9 - 15.2 cu. In)

Reversible hydraulic gear pump. 0.8L (49 cu.in) / min. For cylinder displacement of 80 cc - 250 cc (4.9 - 15.2 cu.in). O-Ring Boss (ORB) connections. Includes 3 x ORB-5 to 9/16 UNF fittings. SteadySteer compatible. (NAC-2 / AC12 required).

• Pump-2 MKII
• 3 x ORB-5 to 9/16 UNF fittings

Simrad Pump-3 12v Hydraulic 1.6L Pumpset

• Reversible Pump
• Moderate Flow Rate
• 12V DC
• 160-550 cc
• 9.8-33.5 cu.in

Reversible hydraulic gear pump. 1.6L (98 cu.in) / min. For cylinder displacement of 160-550 cc (9.8 - 33.5 cu.in). O-Ring Boss (ORB) connections. Includes 3 x ORB-5 to 9/16 UNF fittings. SteadySteer compatible. (NAC-3 / AC42 required).

• Pump-3 MKII
• 3 x ORB-5 to 9/16 UNF fittings

Sirmad Pump-4 MKII 12v Hydraulic 3.0L Pumpset

• Reversible Pump
• High Flow Rate
• 12V DC
• 290-960 cc
• 17.7 - 58.5 cu. in.

Reversible hydraulic gear pump. 3.0L (183 cui) / min. For cylinder displacement of 290 - 960 cc (17.7 - 58.5 cu. in.). O-Ring Boss (ORB) connections. Includes 3 x ORB-5 to 9/16 UNF fittings. SteadySteer compatible. (NAC-3 / AC42 required).

• PUMP-4 MKII 12v
• 3 x ORB-5 to 9/16 UNF fittings

Sirmad Pump-5 MKII 24v Hydraulic 3.0L Pumpset

• Reversible Pump
• High Flow Rate
• 24V DC
• 290-960 cc
• 17.7 - 58.5 cu. in.
• SteadySteer compatible.

PUMP-5: 24V DC: Reversible hydraulic gear pump. 3.0L (183 cui) / min. For cylinder displacement of 290 - 960 cc (17.7 - 58.5 cu. in.). O-Ring Boss (ORB) connections. Includes 3 x ORB-5 to 9/16 UNF fittings. SteadySteer compatible. (NAC-3 / AC42 required).

• Pump-5 24v
• 3 x ORB-5 to 9/16 UNF fittings

Simrad GO9 XSE with HDI Transducer and C-Map Discover microSD

• Easy to use multi touch software
• Safely and easily navigate using your favourite cartography (Insight, Navionics, CMAP)
• Determine depth, bottom type and find fish using one of the many echosounder technology options
• Quick and simple control of entertainment systems connected on NMEA2000
• Vessel circuit control when connected to a C-zone digital switching system
• View and monitor engine data while underway
• Low Profile Glass dash styling
• Super bright widescreen display
• Built in Wi-Fi connectivity
• Software update notifications and downloads when connected to the internet
• Screen mirroring when connected to a mobile device
• Built in 10 Hz GPS antenna
• Dual Micro SD card slot
• Built in echosounder (Broadband & Chirp)
• Built in DownScan and Sidescan Imaging (transducer required)
• Built in Forwardscan Imaging (transducer required)
• Radar port for direct connection to Simrad 3G/4G or Halo Radar scanners
• Operable with OP40/OP50 Remote
• Advanced NMEA2000 networking

The GO9 XSE offers true ease of use with intuitive touchscreen controls that smartphone and tablet users will find instantly familiar. Tap to create or select waypoints, pinch to zoom, or tap and drag to pan smoothly across charts. Simple home screen and menu layouts make all functions quickly accessible, with large and clearly-captioned icons that are easy to recognise and tap.

The GO9 XSE is a full-featured chartplotter, with support for the widest available range of cartography options including C-MAP(R) MAX-N, Navionics(R), Insight(R), Insight Genesis(R), and NV Digital(R) Charts. Navigate confidently to destinations near and far, with the flexibility to choose charts that best fit your needs and location. Set and record those destinations easily with simple waypoint mangement: mark waypoints with a touch, and assign meaningful names that make it easy to look up your desired destination whether you’ve mapped out ten places or a thousand.

The Simrad GO9 XSE is a full-featured radar display with plug-and-play connectivity to Simrad Broadband 3GTM, Broadband 4GTM, and HaloTM Pulse Compression radar systems. Cruise confidently through crowded harbours, navigate safely in poor visibility, keep an eye on distant weather cells, and find flocks of feeding birds that hint at good fishing spots. Automatic tuning helps to provide a clear radar picture in any conditions, while radar overlay combines radar data with navigational charts for an easy-to-interpret view of your surroundings.

Designed for power boaters, TripIntel technology tracks and displays the key information you need to plan safe and enjoyable days on the water. Make smart decisions with fuel range overlaid on charts, easy access to current and future tide levels, and a detailed history of your previous trips including the route you took and how your boat performed.

Easier Navigation with Automatic Routing Automatic routing brings the convenience of in-car navigation to boating, helping you to plot a route and get underway with less delay. Simply select a destination, and your GO XSE display will suggest the shortest, safest route taking into consideration the draught and dimensions of your vessel. This feature is available with Navionics+ or Navionics Platinum charts (Navionics Autorouting), and with Jeppesen CMAP MAX-N+ charts (Jeppesen Easy Routing).

With a high-speed GPS receiver updating your position ten times every second, the Simrad GO9 XSE is ideal for use aboard fast-moving RIBs and powerboats. Watch your boat’s movement tracked smoothly, accurately, and in real-time, without ’jumping’ from point to point on the display.

Designed with power boating in mind, the Simrad GO9 XSE offers a unique Cruise Charting page that brings together crucial navigation data and charts in one easily readable display. Choose the information most relevant to your crusing style and on-water activities with the ability to edit on-screen data items.

The Simrad GO9 XSE connects to any NMEA 2000(R)-capable equipment aboard your vessel including outboard and inboard engines; fuel level and flow meters; speed, heading, and water temperature sensors; and much more. Create your own custom digital instrument displays, bringing a wealth of information to even the most crowded dash while keeping a clean look with as few gauges as possible.

Knowing the true depth beneath your hull can help you enjoy your time on the water with fewer worries, and makes it easier to locate suitable anchorages in unfamiliar waters. With built-in sonar, just add a suitable sonar transducer for accurate, real-time depth tracking. A scrollable depth history view lets you track back and easily set waypoints for promising anchorages, while StructureScan ImagingTM combines DownScan and SideScan sonar to offer a picture-like view of the bottom beneath your vessel.

Using an optional ForwardScan transducer, this forward-looking sonar technology provides a clear two-dimensional image of the bottom in front of your vessel, allowing you to navigate shallow or poorly-charted waters with confidence. With real-time updates and a forward-looking view of up to eight times your current depth, ForwardScan lets you relax and enjoy a safer day on the water.

Whether fishing is your life or just a casual hobby, any fishing trip will benefit from the extensive array of built-in sonar technology on the Simrad GO9 XSE. Add a suitable transducer, available separately or bundled with your display, and the GO9 XSE works as a powerful fishfinder with CHIRP-enabled broadband sonar for clear detection of fish throughout the water column. With an optional HDI or TotalScan transducer, the GO9 XSE also offers StructureScan HD sidescan imaging for a picture-like view of fish-holding structure beneath and around your boat.

If you’re not at home on the water without a good soundtrack, the Simrad SonicHub(R)2 marine audio system is the perfect companion to a GO9 XSE display. Stream music from Bluetooth(R) connected tablets, smartphones, and other mobile devices, play MP3 files from a USB flash drive, or listen to the SonicHub 2’s built-in AM/FM radio. SonicHub 2 brings complete control of your audio entertainment to your GO9 XSE display, eliminating the need for a separate stereo head-unit and letting you listen to your music, your way.

With Wi-Fi built in, the Simrad GO9 XSE provides direct access to GoFree cloud services including easy wireless map downloads, software updates, and more. Whether hooked up to your home Wi-Fi with your boat trailered in the driveway, logged in to your marina’s Wi-Fi, or tethered to your smartphone out on the lake, you can access GoFree cloud services anywhere you have an internet connection. On the water, GoFree connects the Simrad GO9 XSE to your mobile devices, mirroring your display’s screen on your smartphone or giving you full remote control from your tablet with the free GoFree Controller app.

The Simrad GO9 XSE is the only GO Series display compatible with SiriusXM Marine satellite weather, via the optional WM-3 expansion module, for real-time access to weather information right on your display. With onboard access to weather radar, surface buoy reports, NOAA Marine Zone forecasts and more, you can check out the conditions offshore before you even leave the dock. SiriusXM Marine is a subscription service, exclusively available within North America.

* Built-in GPS receiver works in any bracket-mount installation, and when flush-mounted with most fibreglass hulls. When flush-mounted in a metal hulled vessel, an external GPS receiver such as the Simrad GS25 may be required.

• GO9 XSE
• Gimbal bracket, GO9,V9
• GO9 / V9 Bezel Replacement
• GO9/V9 Dash mount kit
• Power Cable
• GO9 XSE Suncover
• HDI Skimmer MED/HIGH 455/800 transdcuer. 9 pin Black Connector
• C-MAP Discover microSD

Simrad NAC-2 Low Current Autopilot Computer

• Recommended for boats up to 10 metres (33 feet) in length
• Plug & Play installation
• Compatible with low-current drive pumps, mechanical drives, hydraulic linear drives, and solenoid valves
• 12 or 24 V DC input 8A continuous output, 12A peak
• Solenoid output capable
• 3 A clutch output
• Optional Auto/Standby Switch
• Drive & Processing circuitry and components identical to commercial autopilots
• Virtual rudder feedback for simplified installation aboard outboard and sterndrive (inboard/outboard) boats
• Rudder feedback options: NMEA2000 Rudder Feedback (RF25), Resistive Rudder -Feedback. New SD10 Mechanical Drive plugs straight in to drive and RFU connectors

The NAC-2 Autopilot Computer is the brains behind your autopilot system. NAC-2 contains the control algorithms developed to helm a yacht across a broad range of weather conditions and sea-states, alongside the electronics needed to operate a hydraulic or mechanical drive unit, while also interfacing with other components including heading sensors and rudder feedback units. The NAC-2 was designed for boats up to 10 metres (33 feet) in length and is suitable for low-current hydraulic drives, mechanical drives, or solenoid valves with a current rating of 8 Amps continuous (12 Amps peak).

• NAC-2
• N2KEXT-2RD - 0.61 m (2-ft) NMEA
• N2K-T-RD T

Simrad A2004 Autpilot Compass Pack

• Proven Simrad interface designed for commercial marine applications
• Large, heavy-duty rotary control dial for precision steering
• Continuum steering technology
• Optically bonded 4.1-inch colour display with 170 deg viewing angle
• Thruster integration & heavy-duty rudder feedback support
• Configurable work mode and low/high speed modes
• Automated turn patterns for fuel-efficient, hands-free manoeuvres
• No Drift steering holds course against wind and tide
• Flush or bracket mounting options
• Certified NMEA 2000(R) connectivity

The A2004 is a dedicated autopilot controller designed to meet the needs of professional mariners aboard a variety of commercial vessels. It features a proven Simrad interface, presented on a wide-angle and zero-fog colour display. Engineered for responsiveness and ease of use, the A2004 pairs a precision rotary control dial with dedicated buttons for instant access to steering modes, a custom-configurable Work mode, and automated turn patterns.

The A2004 builds upon the proven user interface and keypad layout of the Simrad AP70 and AP80 professional autopilot controllers, and delivers consistency with the latest generation of Simrad radar, sonar, and ECDIS displays.A large aluminium rotary control dial enables quick but precise steering adjustments, while dedicated keys offer instant access to steering modes, a custom-configurable Work mode, and automated turn patterns. All built-in controls are designed for ease of use with wet or gloved hands, in commercial settings such as fishing vessels and workboats. The A2004 also supports a wide range of Simrad autopilot remotes and steering levers.

Every Simrad steering innovation builds upon a legacy encompassing over sixty years of autopilot development, which continues to this day. This legacy is exemplified by the Continuum algorithm: the software behind Simrad steering technology. Continuum steering distils years of research and on-water testing into a flexible software solution, capable of delivering reliable auto-steering performance tuned specifically to match a vessel’s control characteristics. With a comprehensive range of hardware and interface modules, Simrad autopilot solutions can be tailored to suit a wide range of commercial vessels and applications.

To ensure optimal visibility in all conditions, the A2004’s colour LCD panel is optically bonded to its protective glass covering - eliminating the possibility of internal condensation. Transflective LCD technology makes use of reflected sunlight to brighten rather than obscure the screen, delivering superior day-time visibility and lower power consumption compared to traditional backlit displays. An ultra-wide 170 degree viewing angle means key autopilot information is clearly visible at a glance, from anywhere in sight of the display.

The A2004 enables autopilot control of a single thruster via an optional AD80 or SD80 interface module. The thruster can be set to engage automatically below a user-defined speed threshold, and configured separately for normal and Work modes. The A2004 also supports specialized heavy-duty rudder feedback units designed for reliable operation aboard commercial vessels.

• A2004 Control
• AC70 Computer
• RF300 Feedback
• Precision 9 Compass

Simrad NSS9 evo3S and Halo20+ Radar bundle

• High Resolution, High Bright, SolarMax IPS Displays
• Easy to use touchscreen UI as well as full keypad for simple and precise control in any sea conditions
• Built-in advanced echosounder capable of 1kW Dual channel CHIRP, Forwardscan, Sidescan, Downscan and StructureScan 3D images
• Take another step forward with Simrad’s premium network modules for the ultimate offshore performance
• Halo Dome and Open Array Radars: S5100 Sportfishing Echosounder, Direct audio, autopilot and engine connection and control
• Low profile glass dash styling
• Built in Wi-Fi connectivity
• Next Generation Processor
• SolarMAX IPS Display Technology
• Multi-touch screen and keypad hybrid control
• Built-in Advanced Echosounder

NSS evo3S is a mid-life update to the NSS evo3. The key difference is a next generation processor. This greatly improves the speed and smoothness of the display. The NSS evo3 is already a feature packed product and the new processor in the evo3S means that each one of those features is now improved

Simrad NSS12 evo3 + Halo20+ Radar bundle

• High Resolution, High Bright, SolarMax IPS Displays
• Easy to use touchscreen UI as well as full keypad for simple and precise control in any sea conditions
• Built-in advanced echosounder capable of 1kW Dual channel CHIRP, Forwardscan, Sidescan, Downscan and StructureScan 3D images
• Take another step forward with Simrad’s premium network modules for the ultimate offshore performance
• Halo Dome and Open Array Radars: S5100 Sportfishing Echosounder, Direct audio, autopilot and engine connection and control
• Low profile glass dash styling
• Built in Wi-Fi connectivity
• Next Generation Processor
• SolarMAX IPS Display Technology
• Multi-touch screen and keypad hybrid control
• Built-in Advanced Echosounder

NSS evo3S is a mid-life update to the NSS evo3. The key difference is a next generation processor. This greatly improves the speed and smoothness of the display. The NSS evo3 is already a feature packed product and the new processor in the evo3S means that each one of those features is now improved

Simrad Autopilot Gateway for Yamaha

• Fully integrated with your Simrad Navigation system via NSS, NSO, GO
• Control the SG05 Autopilot directly from your MFD
• All the modes you’d expect from a Simrad Autopilot: Auto, Nav, NoDrift, FollowUp

Simrad NAC-3 High Current Autopilot Computer

• B&G Reflex Sailing algorithms
• 12/24V input 30A continuous output (50A peak)
• 3A Clutch output
• NMEA 0183 Interface (1 input, 1 output)
• Solenoid output capable
• Rudder feedback options: NMEA2000 Rudder Feedback (RF25), Freq. Rudder -Feedback (RF300)
• Solenoid output capable for larger vessels
• Connection for NFU Remotes
• External Mode input, External open/close or pulse contact for SYSTEM SELECT
• External alarm output for buzzer/relay

The NAC-3 Autopilot Computer is the brains behind your autopilot system. NAC-3 contains the control algorithms developed to helm a yacht across a broad range of weather conditions and sea-states, alongside the electronics needed to operate a hydraulic or mechanical drive unit, while also interfacing with other components including heading sensors and rudder feedback units. The NAC-3 was designed for boats 10 metres (33 feet) or greater in length and is rated to operate high-current hydraulic drives, mechanical drive units, and solenoid valves with a current rating of 30 Amps continuous (50 Amps peak).

• NAC-3
• N2KEXT-2RD - 0.61 m (2-ft) NMEA
• N2K-T-RD T

Simrad S5100 High-Performance CHIRP Sonar Module

• Three fully independent sonar channels deliver high-resolution coverage
• Noise-free clarity at all depth ranges
• Combine any three frequency ranges to target multiple depths, including Ultra-Low, Low, Medium, or High CHIRP
• Compatible with wide-angle CHIRP transducers for greater coverage of the water column
• Simultaneous split-screen viewing of multiple depth ranges on your display
• Maximum depth of 3,000 metres / 10,000 feet (transducer dependent)
• Easy to install with three plug-and-play 9-pin transducer connectors
• Compatible with Simrad NSS evo3 and NSS evo2 multifunction displays, NSO evo2 systems, and S2000-series fish finders

The S5100 high-performance CHIRP sonar module features three fully independent channels able to deliver high-resolution sonar coverage across multiple depth ranges, precision-focused for offshore sportfishing anglers. Simultaneous split-screen viewing capability puts you in complete control of the water column, while advanced processing technology allows you to fish with noise-free clarity at all depth ranges without ever losing bottom depth tracking. Mix and match your favourite transducer coverage and transmit power for wide and narrow beam-widths to reveal more fish, detecting small and tightly spaced fish and identifying thermoclines; or adjust specific CHIRP frequencies from 28 to 250 kHz to precisely target specific depths producing big, crisp arches with clear target separation.

• S5100 Module
• Powercord
• 4.5m Ethernet cable
• 7 TO 9 Pin Adapter Cable X 3

Simrad A2004 Autopilot Pack with HS75 - no Drive

• Proven Simrad interface designed for commercial marine applications
• Large, heavy-duty rotary control dial for precision steering
• Continuum steering technology
• Optically bonded 4.1-inch colour display with 170 deg viewing angle
• Thruster integration & heavy-duty rudder feedback support
• Configurable work mode and low/high speed modes
• Automated turn patterns for fuel-efficient, hands-free manoeuvres
• No Drift steering holds course against wind and tide
• Flush or bracket mounting options
• Certified NMEA 2000(R) connectivity

A2004 Autopilot pack with A2004 controller, AC70 Autopilot computer, RF300 rudder feedback and a HS75 GPS compass. For use with non-IMO professional vessels. For reversible pumps or non-isolated solenoid valve controls. Add either an AD80 or SD80 for thruster control.

The A2004 is a dedicated autopilot controller designed to meet the needs of professional mariners aboard a variety of commercial vessels. It features a proven Simrad interface, presented on a wide-angle and zero-fog colour display. Engineered for responsiveness and ease of use, the A2004 pairs a precision rotary control dial with dedicated buttons for instant access to steering modes, a custom-configurable Work mode, and automated turn patterns.

The A2004 builds upon the proven user interface and keypad layout of the Simrad AP70 and AP80 professional autopilot controllers, and delivers consistency with the latest generation of Simrad radar, sonar, and ECDIS displays.A large aluminium rotary control dial enables quick but precise steering adjustments, while dedicated keys offer instant access to steering modes, a custom-configurable Work mode, and automated turn patterns. All built-in controls are designed for ease of use with wet or gloved hands, in commercial settings such as fishing vessels and workboats. The A2004 also supports a wide range of Simrad autopilot remotes and steering levers.

Every Simrad steering innovation builds upon a legacy encompassing over sixty years of autopilot development, which continues to this day. This legacy is exemplified by the Continuum algorithm: the software behind Simrad steering technology. Continuum steering distils years of research and on-water testing into a flexible software solution, capable of delivering reliable auto-steering performance tuned specifically to match a vessel’s control characteristics. With a comprehensive range of hardware and interface modules, Simrad autopilot solutions can be tailored to suit a wide range of commercial vessels and applications.

To ensure optimal visibility in all conditions, the A2004’s colour LCD panel is optically bonded to its protective glass covering - eliminating the possibility of internal condensation. Transflective LCD technology makes use of reflected sunlight to brighten rather than obscure the screen, delivering superior day-time visibility and lower power consumption compared to traditional backlit displays. An ultra-wide 170 degree viewing angle means key autopilot information is clearly visible at a glance, from anywhere in sight of the display.

The A2004 enables autopilot control of a single thruster via an optional AD80 or SD80 interface module. The thruster can be set to engage automatically below a user-defined speed threshold, and configured separately for normal and Work modes. The A2004 also supports specialized heavy-duty rudder feedback units designed for reliable operation aboard commercial vessels.

• A2004 Autopilot Control Unit
• AC70 Autopilot Computer
• RF300 Rudder feedback
• NMEA2000 15 feet cable
• HS75 GPS Compass

Simrad TM260 Plastic transom-mount. 50/200Khz with diplexer. 9-pin

Powerful, Yet Sensitive! The TM260 takes the legendary performance of the B260 to your vessel’s transom. This top-of-the-line, broadband, transom-mount brings crystal clear imaging to any of today’s fishfinders. The large, 200 kHz element and the seven-element, 50 kHz array are excellent for bait and game fish separation along with detecting ground fish holding tight to the bottom. The TM260’s rugged mounting bracket is easy-to-install and has a streamlined shape that delivers high-speed performance up to 30 knots (35 MPH).

Simrad Bronze HDI XDCR 0deg Tilt 50/200 455/800

• Provides 50/200kHz traditional frequencies PLUS 455/800kHz Down Scan Imaging plus temperature

The transducer comes with a 33 ft cable and Black 9 Pin connector which plugs directly into a compatible echosounder. The transducer must be selected in the installation menu on the device.

Simrad NAC-D Autopilot Computer

• SeaStar Solutions(R), Volvo(R), Yanmar(R) and Yamaha(R) approved control system interface
• Control via APTM 44, AP 48 or easily integrate with your Simrad(R) multifunction display
• No need for an additional hydraulic pump, rudder sensor, or dockside calibration
• SteadySteerTM feature included
• Steer to a waypoint, heading or set turn pattern, such as a U turn, Spiral turn and many more - the NACTM -D can even initiate a zigzag turn
• CAN-bus data connectivity - connection to Optimus(R) steering systems via the CAN-bus data network
• Full system integration with Simrad(R) navigation systems via NSSTM and NSOTM multifunction display ranges

NACTM -D is a steer-by-wire autopilot solution for Electronic Vessel Control Systems (steering systems with a digital interface).

With NAC -D, boaters with SeaStar(R) Optimus(R), Yanmar(R) VC10/JC10, Volvo(R) IPS/EVC or Yamaha(R) helm master/single engine control systems can benefit from all the full features and performance of Simrad(R) autopilots.

Requires only the connection of two Micro-C connectors - there is no requirement for an additional hydraulic pump, rudder sensor installation or dockside rudder calibration. This saves boaters’ time and money.

Featuring Continuum(R) steering and support for the new SteadySteerTM, the NAC -D allows automatic switching between two speed profiles delivering optimal steering performance at both low and high speeds.

Choose the controller to suit your preference from dedicated controllers like the APTM 44 or AP 48, or simply integrate with your Simrad(R) multifunction display.

Simrad(R) autopilot systems incorporate state-of-the-art electronics and represent over 70 years of experience and development. Simrad(R) autopilots can reduce your workload and fatigue and improve your situational awareness and safety, helping you arrive fresher at your destination.

Simrad RS100 Black Box VHF System

• Class D DSC approved VHF radio
• Integrated GPS receiver
• Connect up to four wireless and four wired handsets
• Add an optional loudhailer and up to four external speakers
• NMEA 0183(R) and NMEA 2000(R) connectivity
• 60-second audio rewind
• Configurable external speakers with volume offsetting
• Handset backlight settings can be grouped with NMEA 2000(R) backlight groups so MFD’s and VHF Radios can have backlight controlled together
• Track Buddy - track up to five "buddies" using their VHF MMSI

Navigate safely with the Simrad RS100 VHF marine radio. Stay connected from anywhere on your vessel with up to eight handsets (four wired and four wireless) and four external speakers. Add an optional external GPS-500 for advanced positioning data (AIS functionality).

The RS100 is a modular VHF system that’s expandable and customisable to suit any boat and any on-water communication needs. The standard package includes one wired handset and one external speaker. This setup is expandable up to eight handsets (four wired and four wireless) and four external speakers - ideal for use as an on-board intercom with Simrad HS40 wireless or HS100 wired handsets. The wireless handsets duplicate the radio display and controls on easy-to-read screens viewable under all lighting conditions, even bright sunlight. All primary functions are accessible from the handset with channel scan and favourites, alphanumeric keypad, clear audio, handset station naming and 60-second audio rewind.

This Class D DSC approved radio can make and receive DSC distress signals including your current position, and supports direct calling to other DSC-equipped radios. A dual-channel watch lets you monitor the current channel and emergency channel 16 (in the USA, tri-channel watch monitors the current channel, emergency channel 16, and calling channel 9). A record and replay feature helps to ensure you never miss an important call. The system includes one external speaker with additional outputs for up to four speakers and one optional loudhailer/foghorn.

• NRS-1 VHF marine VHF radio: Black box only.
• HS-100 Wired handset
• SP100 - Speaker

Simrad IS42 Digital Display

• Optically bonded 4.1-inch colour display
• Display wind, speed, depth, engine data, autopilot status and more
• Intuitive operation
• Easy installation
• Add an OP12 keypad for full Simrad autopilot control
• Compatible with Simrad AC12, AC42, NAC-2 and NAC-3 autopilot computers
• Low power consumption-
• Low-profile glass helm design
• Advanced AIS, receive AIS messages and call DSC targets* (*Compatible VHF required)
• Certified NMEA 2000(R) connectivity

Multi-purpose sailing instrument and autopilot display with a 4.1-inch colour screen, optically bonded for zero condensation and featuring transflective LCD technology for exceptional contrast and visibility in all lighting conditions. 8mm mounting height matches other Simrad MFD’s and system components.

The IS42 is a smart multi-purpose instrument featuring a full colour display and modern glass helm styling. View wind, speed, depth, engine data, autopilot status and more at a glance, or add the optional OP12 keypad to take full control of your Simrad autopilot system. The IS42 integrates brilliantly with Simrad multifunction displays and glass helm systems, or can function as a standalone instrument display and autopilot controller aboard smaller vessels.

Simrad OP12 Autopilot Controller

• Intuitive operation
• Easy installation
• Combine with an IS42 display for full autopilot control
• Compatible with Simrad AC12, AC42, NAC-2 and NAC-3 autopilot computers
• Use alongside NSS & NSO evo2/3 MFD’s as an additional Autopilot Controller
• Low-profile glass helm design
• Low power consumption
• Certified NMEA 2000(R) connectivity

The OP12 wired remote seamlessly integrates with Simrad autopilot systems to provide intuitive mode control, course adjustments, and power steering. Designed to complement the low-profile design of Simrad glass bridge instruments and displays, this remote can be combined with the IS42 Colour Instrument Display to create a standalone autopilot controller, or used as a dedicated autopilot keypad for GO, NSS and NSO evo2 multifunction displays.

Intuitive operation A simple pushbutton interface makes the OP12 easy to use in rough conditions, and reliably responsive to wet or gloved hands. Dedicated auto and standby buttons enable or disable the autopilot with a single press, so it’s easy to free your hands from the wheel or instantly take control whenever you need to. Course adjustments are also just one button-press away, with dual port and starboard buttons to enable course adjustments in either one-degree or ten-degree increments.

Low-profile glass helm design Designed to complement Simrad glass helm displays and instruments, the OP12 features modern styling with a low surface-mount profile of just eight millimetres. A compact footprint enables mounting almost anywhere, while still offering large buttons for easy and reliable operation.

• OP12 Autopilot Controller
• N2K-T-RD Network T-Connector
• N2KEXT-2RD 2ft Network Extension Cable
• Suncover for Triton2 Pilot/OP12

Simrad Bronze HDI XDCR 12deg Tilt 50/200 455/800

• Provides 50/200kHz traditional frequencies PLUS 455/800kHz Down Scan Imaging plus temperature

The transducer comes with a 33 ft cable and Black 9 Pin connector which plugs directly into a compatible echosounder. The transducer must be selected in the installation menu on the device.

Simrad Bronze HDI XDCR 20deg Tilt 50/200 455/800

• Provides 50/200kHz traditional frequencies PLUS 455/800kHz Down Scan Imaging plus temperature

The transducer comes with a 33 ft cable and Black 9 Pin connector which plugs directly into a compatible echosounder. The transducer must be selected in the installation menu on the device.

Simrad SS75M 12 Degree Tilt

• CHIRP transducers enable bottom detection with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures.
• Calculates how deep the water is, so that you can avoid running aground, whilst also incorporating a temperature sensor for accurate water temperature readings.
• CHIRP range is 80kHz-130kHz for good target detail in shallow water and excellent bottom tracking in deep water.
• Provides extremely accurate data.
• The 12 deg tilt is ideal for boats with a 8 deg to 15 deg hull deadrise.
• The low profile housing minimizes drag with just 5mm extending outside of the hull.
• Easily connect to NSSevo3

The SS75M is a bronze, thru-hull, tilted, medium-frequency (80-130kHz), depth and temperature transducer. The ceramic element is tilted for built-in deadrise compensation, giving excellent echo returns for more accurate depth readings.

Simrad SS75M 20 Degree Tilt

• CHIRP transducers enable bottom detection with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures.
• Calculates how deep the water is, so that you can avoid running aground, whilst also incorporating a temperature sensor for accurate water temperature readings.
• CHIRP range is 80kHz-130kHz for good target detail in shallow water and excellent bottom tracking in deep water.
• Provides extremely accurate data.
• The 20 deg tilt is ideal for boats with a 16 deg to 24 deg hull deadrise.
• The low profile housing minimizes drag with just 5mm extending outside of the hull.
• Easily connect to NSSevo3

The SS75M is a bronze, thru-hull, tilted, medium-frequency (80-130kHz), depth and temperature transducer. The ceramic element is tilted for built-in deadrise compensation, giving excellent echo returns for more accurate depth readings.

Simrad HS100/SP100 Wired Handset and Speaker for S100/RS100B

• Style to match Simrad wireless handsets and MFD’s
• Large clear white dot matrix LCD
• Inverted LCD night mode for reduced light emission
• Dimmable to low output level for night operation
• Easy channel Scan and Favourites options
• Alphanumeric Keypad
• Clear Audio from Handset Speaker and Microphone
• Handset Station Naming
• 60 Second audio rewind
• Up to four speakers can be configured to one wired handset with an individual offset for each speaker.
• When a speaker is mounted further from a user than the wired handset or additional speaker, an offset can be applied to the speaker to achieve volume consistency.
• Speaker volume will be controlled by the wired handset the speaker is assigned to with the volume offset selected.
• Handset speakers can be turned off should the user only wish for external speaker audio.

• HS100 Handset
• Cradle for HS100 & H100 VHF radio handsets
• SP100 Speaker

Simrad HS100 Wired Handset Only for S100/RS100B

• Style to match Simrad wireless handsets and MFD’s
• Large clear white dot matrix LCD
• Inverted LCD night mode for reduced light emission
• Dimmable to low output level for night operation
• Easy channel Scan and Favourites options
• Alphanumeric Keypad
• Clear Audio from Handset Speaker and Microphone
• Handset Station Naming
• 60 Second audio rewind

• HS100 Handset
• Cradle for HS100 & H100 VHF radio handsets

Simrad SP100 Speaker only for RS100, RS100-B, V100 and V100-B Blackbox VHF Systems.

• Up to four speakers can be configured to one wired handset with an individual offset for each speaker.
• When a speaker is mounted further from a user than the wired handset or additional speaker, an offset can be applied to the speaker to achieve volume consistency.
• Speaker volume will be controlled by the wired handset the speaker is assigned to with the volume offset selected.
• Cable length included, 5m (16.4ft)
• Handset speakers can be turned off should the user only wish for external speaker audio.

Simrad Pole Mount Kit for HS75

• Screw the jam nut onto the 1-inch pole, then screw the pole mount bracket onto the pole. Do not tighten the pole mount to more than 5.4 Nm (4 lbs-ft).
• Feed the cable either through the hollow pole or through the opening in the pole mount bracket.
• Connect the NMEA 2000 drop cable to the HS75, then secure the pole mount bracket to the HS75 using the supplied mounting hardware. Tighten to a torque of 11 - 13 Nm (8 - 10 lbs-ft). The maximum thread depth engagement must be no more than 12 mm (0.50 in).
• Verify the orientation of the HS75, then tighten the jam nut to the bottom of the pole mount

Pole Mount Bracket for HS75 - Standard 1 feet’ 14TPI threads.

Simrad AP44 Rotary Dial Autopilot Control Head

• Rotary-dial course adjustment with new intuitive autopilot control
• Optically bonded 4.1-inch color display
• Easy setup with auto tuning and calibration
• Simrad Continuum steering technology
• All new intuitive autopilot control
• Automated turn patterns
• No Drift steering
• Depth contour tracking
• Low-profile ’Glass Helm’ design
• Low power consumption
• Certified NMEA 2000(R) connectivity

The AP44 Autopilot Controller combines Simrad Continuum steering technology with a full colour display, intuitive rotary dial and button controls, and modern glass helm styling. Free your hands from the wheel, cruise in comfort, and discover new ways to search for fish; this dedicated controller offers easy access to automated turn patterns, No Drift steering, depth contour tracking, and other advanced pilot features. Connect your chartplotter to add waypoint and route navigation, and enjoy full autopilot control from compatible Simrad displays.

The point of a dedicated autopilot controller is to enable immediate access to auto-steering functionality, placing key controls within easy reach. Designed with that purpose in mind, the AP44 includes an intuitive interface with just four buttons and a push-to-enter rotary control dial

Your Simrad autopilot can do much more than keep you on course. The AP44 gives you easy access to a range of built-in turn patterns designed to assist with fishing, diving, or just making a quick and efficient U-turn.

Every Simrad steering innovation builds upon a legacy encompassing over sixty years of autopilot development, which continues today at Simrad Yachting’s autopilot research hub in Norway

Autopilot installation and commissioning doesn’t have to be difficult or time consuming. The AP44 offers automatic tuning to ensure optimal auto-steering performance, with a simple on-screen commissioning process including dockside configuration and sea trial

Simrad AP44M-VRF Medium Capacity Autopilot MKII Pump, SteadySteer Compatible

• Rotary-dial course adjustment with new intuitive autopilot control
• Optically bonded 4.1-inch color display
• Easy setup with auto tuning and calibration
• Simrad Continuum steering technology
• All new intuitive autopilot control
• Automated turn patterns
• No Drift steering
• Depth contour tracking
• Low-profile ’Glass Helm’ design
• Low power consumption
• Certified NMEA 2000(R) connectivity

The AP44 Autopilot Controller combines Simrad Continuum steering technology with a full color display, intuitive rotary dial and button controls, and modern glass helm styling. Free your hands from the wheel, cruise in comfort, and discover new ways to search for fish; this dedicated controller offers easy access to automated turn patterns, No Drift steering, depth contour tracking, and other advanced pilot features. Connect your chart plotter to add waypoint and route navigation, and enjoy full autopilot control from compatible Simrad displays.

The NAC-2 Autopilot Computer is the brains behind your autopilot system. NAC-2 contains the control algorithms developed to helm a yacht across a broad range of weather conditions and sea-states, alongside the electronics needed to operate a hydraulic or mechanical drive unit, while also interfacing with other components including heading sensors and rudder feedback units. The NAC-2 was designed for boats up to 10 metres (33 feet) in length.

• AP44 Autopilot controller
• NAC-2 Autopilot Computer
• PRECISION-9 COMPASS
• N2K-PWR-RD
• TR-120-KIT
• PUMP-2 NKII : 12V DC: 3 x ORB-5 to 9/16 UNF fittings

Simrad XSONIC SS75H CHIRP Thru Hull 9-Pin 12 Degree Tilted Element

• Depth & Temperature
• High Frequency 130-210 kHz
• 600 W
• High-Performance
• Stainless Steel
• Exclusive Transducer ID

Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000 feet) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 80 kHz of total bandwidth in just one installation, saving customers time and money.

Simrad M260 9-pin In-hull transducer

• 50 kHz with 19 deg beam width
• 200 kHz with 6 deg beam width
• Up to 900 m (3000 ft) range at 50 kHz
• 8 internal broadband ceramics
• In-Hull with plastic/urethane housing and yellow in-hull tank (can mount in existing M260 installed tanks)
• Suitable for fiberglass hulls
• Ideal for sportfishing and commercial vessels 8 m (25 ft) and up
• Recommended for use with the SonarHub sounder module, Simrad NSSevo3 sport multifunction displays

The M260 is a plastic/urethane, in-hull Broadband transducer, ideal for smaller sportfishing and commercial vessels 8 m (25 ft) and up, fishing in depths of less than 900 m (3000 ft). Black 9 Pin connector

The dual-frequency M260 includes an array of seven ceramic elements delivering 50 kHz with a 19 deg beam width, and a single 200 kHz element with a 6 deg beam width. 50 kHz low-frequency operation offers a maximum operational depth of 900 m (3000 ft), while 200 kHz high-frequency provides higher-resolution fish arches and bottom detail in shallower water.

Simrad XSONIC P319 50/200Khz Plastic Thru Hull with 9-Pin connector

• Depth and temperature
• Good target detail in shallow-water at 200 kHz and good deep-water bottom tracking at 50 kHz
• Right angle cable exit offers low headroom and protection when transducer is stepped on
• Included rubber washer allows tightening of the hull nut to irregular hull surfaces
• Housings are ABYC H-27 compliant
• Plastic transducer housing

The P319 features our 50/200 kHz, dual-frequency, single-ceramic element in a low-profile housing. The nearly-flush design minimizes drag with only 5 mm (3/16) extending outside of the hull. The bronze B117 and stainless steel SS60 models are also available to accommodate all hull materials.

Simrad XSONIC SS164 50/200Khz 0 Degree Tilt 9-Pin Connector

• Depth & Temperature
• 50/200 kHz
• 1 kW RMS
• High-Performance
• Stainless Steel

Specifically designed for metal-hull boats, Airmar has taken our innovative Tilted ElementTM technology to a higher power. The SS164, 1kW transducer is perfect for fast, tailored tournament-sportfishing vessels that cannot have a High-Performance Fairing. The flush mounted, stainless steel housing protrudes less than 6.35 mm (0.25 in) outside your hull and can sit on trailer rollers and bunks with no damage at all. The ceramic arrays are tilted inside the housing giving you the perfect vertical beam with maximum energy on what is directly below your boat. And 1kW takes your fish finder to the next power.

Simrad XSONIC SS164 50/200Khz 12 Degree Tilt 9-Pin Connector

• Depth & Temperature
• 50/200 kHz
• 1 kW RMS
• High-Performance
• Stainless Steel

Specifically designed for metal-hull boats, Airmar has taken our innovative Tilted ElementTM technology to a higher power. The SS164, 1kW transducer is perfect for fast, tailored tournament-sportfishing vessels that cannot have a High-Performance Fairing. The flush mounted, stainless steel housing protrudes less than 6.35 mm (0.25 in) outside your hull and can sit on trailer rollers and bunks with no damage at all. The ceramic arrays are tilted inside the housing giving you the perfect vertical beam with maximum energy on what is directly below your boat. And 1kW takes your fish finder to the next power.

Simrad Steadysteer Flow Switch

• Smoother steering
• Use helm to control autopilot
• Steer manually through turns - convenient manual override
• Autopilot engages automatically on straight legs
• Seamless and intuitive boat control
• Fuss free autopilot operation for hydraulic steering

With SteadySteer boaters can take immediate, manual control of the vessel through turns without having to disengage the autopilot. Coming out of turns, it automatically reengages the autopilot once a new heading is established.

SteadySteer automatically disengages the autopilot when you turn the vessel manually and then reengages the autopilot when you have established a new heading. No key-presses, no alarms - just turn the helm.

No need to look at a display or push buttons to change course, just point the bow to your destination.

Compatible with NAC-2, NAC-3 (sw version 1.1.01.00 and newer), AP44, IS42, and AP48 (sw version 57.3.163 or newer), Simrad MFDs (sw version 20.2 or newer) Requires AP44, IS42, or AP48 to work with select, older Simrad MFDs

• Steadysteer Flow Switch

Simrad IDST-810 active Depth, Speed, Temperature thru-Hull plastic 235 kHz transducer.

• 5 Hz speed output (5X per second) for visibly smoother speed-through-water reporting and faster data for better decision making
• Integrated attitude sensor for heel and trim benefits sailing and power boats
• Advanced Speed Calibration allows for manual speed entries for multiple heel angles and up to 10 speeds, formerly only possible through expensive PC software
• DST810 stores configurations and delivers data to the NMEA 2000(R) network.
• Depth, heel-corrected speed-through-water, heel and trim, and water temperature from one installed multisensor.
• Popular depth sensor for shallow water performance.

• DST-810 Insert
• Plastic Housing

Simrad IS42 Speed/Depth Package with DST810 Transducer

• Optically bonded 4.1-inch colour display
• Display wind, speed, depth, engine data, autopilot status and more
• Intuitive operation
• Easy installation
• Add an OP12 keypad for full Simrad autopilot control
• Compatible with Simrad AC12, AC42, NAC-2 and NAC-3 autopilot computers
• Low power consumption-
• Low-profile glass helm design
• Advanced AIS, receive AIS messages and call DSC targets* (*Compatible VHF required)
• Certified NMEA 2000(R) connectivity

Multi-purpose sailing instrument and autopilot display with a 4.1-inch colour screen, optically bonded for zero condensation and featuring transflective LCD technology for exceptional contrast and visibility in all lighting conditions. 8mm mounting height matches other Simrad MFD’s and system components.

The IS42 is a smart multi-purpose instrument featuring a full colour display and modern glass helm styling. View wind, speed, depth, engine data, autopilot status and more at a glance, or add the optional OP12 keypad to take full control of your Simrad autopilot system. The IS42 integrates brilliantly with Simrad multifunction displays and glass helm systems, or can function as a standalone instrument display and autopilot controller aboard smaller vessels.

Simrad IS35 Digital Gauge with Bonded Display

• Automatic display of prioritized dynamic data types. (RPM, fuel flow, economy, speed etc.)
• Bright, full color 240 x 360 LED screen makes it easier to see menus and screen detail in both full sunlight and night operation.
• Menu button doubles as backlight control.
• Simple menu navigation using menu, arrow and enter buttons.
• Easily swap between pages using arrow keys.
• Page cycle with configurable times.
• Surface mount, or flush/rear mount option.
• Fits standard gauge hole
• Display NMEA2000 engine information affordably
• Automatically displays information relevant to which sensors are installed
• Automatic page scrolling with configurable adjustable delay time

The IS35 is used to display engine and vessel related data on the network provided by NMEA2000 compatible engines and sensors. The types of data available for display are determined by the available NMEA2000 sensors on the network. You can use the IS35 as engine display for most types of marine engines, either via a NMEA2000 gateway, or a J1939 to NMEA2000 convertor. (for example the Livorsi CAN Data Gateway). The IS35 comes with 5 pre-configured pages for the most commonly used information when operating vessels. The information on these pages is automatically displayed from an internal hierarchy of available data. The hierarchy was developed from market and customer surveys about which information the boat owners themselves consider the most important information to see on their displays.

User Interface The IS35 is running on the NOS (Navico Operating System) platform. Anyone that is familiar with Navico products will quickly and easily understand the user interface of the IS35. Power Control The unit automatically starts up when N2K bus is powered. The IS35 can’t be powered off but can be put into standby. Refueling You can quickly set the fuel to full, or add a fuel amount directly from pressing menu on the fuel page, or by the settings menu and going to ’Fuel’. Auto scroll The IS35 can be set to automatically scroll through the pages ranging from 1 to 10 seconds.

Simrad XSONIC SS164 50/200Khz 20 Degree Tilt 9-Pin Connector

• Depth & Temperature
• 50/200 kHz
• 1 kW RMS
• High-Performance
• Stainless Steel

Specifically designed for metal-hull boats, Airmar has taken our innovative Tilted ElementTM technology to a higher power. The SS164, 1kW transducer is perfect for fast, tailored tournament-sportfishing vessels that cannot have a High-Performance Fairing. The flush mounted, stainless steel housing protrudes less than 6.35 mm (0.25 in) outside your hull and can sit on trailer rollers and bunks with no damage at all. The ceramic arrays are tilted inside the housing giving you the perfect vertical beam with maximum energy on what is directly below your boat. And 1kW takes your fish finder to the next power.

Simrad P66 Xsonic 50/200Khz 9-Pin Transom Mount

• Depth and temperature in one housing
• Plastic kick-up bracket
• Accommodates transom angles between 2 deg and 20 deg
• Recessed waterflow channel protects paddlewheel
• Transducer can be removed from bracket without the use of tools for easy service and storage
• Boat Size: Up to 12 m (40 feet)

Airmar(R) P66 Transom Mount Depth/Temp Transducer

The P66 features a 50/200 kHz, dual-frequency, single-ceramic element. This hydrodynamic housing with a rounded nose reduces the turbulence under the transducer’s face for clear display images.

Simrad XSONIC B150M 95-155Khz CHIRP 0 Degree Tilt 9-Pin Thru Hull

• Depth and fast-response water-temperature sensor
• Ideal for inshore or coastal fishing in shallow to medium depths
• Freshwater anglers will see fish holding close to structures and suspended fish
• Track bottom at higher boat speeds
• More coverage under your boat delivers wider arches and 26 deg to 17 deg beamwidths
• Cover the medium frequency range-CHIRPs from 95-155kHz to provide 60 kHz of total bandwidth from one transducer
• Hull Type: Fiberglass, wood or metal
• 1 internal ceramic

As Chirp continues to redefine recreational fishing, AIRMAR has expanded the lineup of broadband transducers to satisfy the growing demand for this game changing technology. New to the market are the B150M and TM150M, economical Chirp transducers designed for offshore fishing and freshwater anglers. Operating at a frequency range of 95-155 kHz, these transducers reveal fish in shallow, murky waters at medium depths (up to 2,500 feet*) along with ultra-clear target resolution..

Simrad XSONIC B150M 95-155Khz CHIRP 12 Degree Tilt 9-Pin Thru Hull

• Depth and fast-response water-temperature sensor
• Ideal for inshore or coastal fishing in shallow to medium depths
• Freshwater anglers will see fish holding close to structures and suspended fish
• Track bottom at higher boat speeds
• More coverage under your boat delivers wider arches and 26 deg to 17 deg beamwidths
• Cover the medium frequency range-CHIRPs from 95-155kHz to provide 60 kHz of total bandwidth from one transducer
• Hull Type: Fiberglass, wood or metal
• 1 internal ceramic

As Chirp continues to redefine recreational fishing, AIRMAR has expanded the lineup of broadband transducers to satisfy the growing demand for this game changing technology. New to the market are the B150M and TM150M, economical Chirp transducers designed for offshore fishing and freshwater anglers. Operating at a frequency range of 95-155 kHz, these transducers reveal fish in shallow, murky waters at medium depths (up to 2,500 feet*) along with ultra-clear target resolution..

Simrad xSonic Airmar B150M Transducer 20 deg Tilt

• Ideal for inshore or coastal fishing in shallow to medium depths
• CHIRPs from 95-155kHz to provide 60kHz of total bandwidth from one transducer
• Black 9 pin connector
• Cable length 10 m (33.0 ft)

The B150M is a bronze, thru-hull CHIRP transducer, ideal for sportfishing and commercial vessels up to 8m (25ft) in length.This single-channel transducer offers Medium CHIRP for a balance between the great depth penetration of Low CHIRP, and the superior target resolution of High CHIRP.

Simrad IDST-810 active Depth, Speed, Temperature thru-Hull Bronze 235 kHz transducer.

• 5 Hz speed output (5X per second) for visibly smoother speed-through-water reporting and faster data for better decision making
• Integrated attitude sensor for heel and trim benefits sailing and power boats
• Advanced Speed Calibration allows for manual speed entries for multiple heel angles and up to 10 speeds, formerly only possible through expensive PC software
• DST810 stores configurations and delivers data to the NMEA 2000(R) network.
• Depth, heel-corrected speed-through-water, heel and trim, and water temperature from one installed multisensor.
• Popular depth sensor for shallow water performance.

• DST-810 Insert
• Bronze Housing

Simrad RI-50 Power Supply for Halo 200x and 300X radars

• Accommodates 12- and 24-volt systems and used for all HALO 2000 and 3000 models
• Same dimensions and mounting template as RI-12
• Supplies 50 V DC to the pedestal in Tx mode
• Improved external POWER/FAULT/STATUS/ETHERNET LED indicator lights
• Internal BLOWN FUSE indicator light for diagnostics
• Supplies parking voltage control to pedestal using low current
• Ethernet output with ETHERNET LED (pigtail adapter supplied for Internal RJ45 to external Navico Yellow)
• Note: no NMEA2000 connection (NMEA data converted by the MFD and passed over ethernet)

• RI-50 Power Supply
• Ethernet Cable 1.8m - 000-0127-51
• RJ45 M to 5 pin F Ethernet Adapter - 000-11246-001

Simrad Halo 2003 50w Pulse Compression Radar System with 3 feet Antenna, 20m Cable and RI-50

• HALO 2000 - 50W power for longer range (from 6m to up to 72nm) and higher-resolution target detection
• Advanced pulse compression technology with beam sharpening
• Simultaneous Dual Range operation
• Easy operation with Harbour, Offshore, Weather, and Bird modes
• Track up to 50 targets per defined area with ZoneTrack (two areas can be defined)
• VelocityTrack Doppler technology for collision avoidance
• Dangerous Target Alerts for radar and AIS targets
• Ready instantly from standby, and in 16-25 seconds from power-on

Benefit from safer navigation and unmatched ease of use with the new HALO(R) 2000 and 3000 Open Array radars. Advanced Pulse Compression technology allows you to detect birds, hazards and storms with superior precision across both short and long distances. While the range of Preset Modes and enhanced power provide constant peace of mind.

The HALO(R) 2000 radar offers a premium experience on the water. An impressive 50 W of power - equivalent to a 12 kW magnetron radar - delivers an unrivaled combination of short- and long-range coverage that enables you to see targets from six meters (20 feet) out to 72 nautical miles with exceptional clarity. Pulse Compression technology powers confident navigation through marinas, and superior storm and hazard detection across a greater distance. The HALO(R) array series not only increase situational awareness and collision avoidance but also offer higher-resolution target detection you won’t find in lower-powered radars.

The HALO 2000 series boast an array of new features that make navigation safer and offer peace of mind. ZoneTrackTM brings the best of professional boating technology to recreational users, allowing them to track up to 50 vessels within a defined area, automatically detecting their course and speed. HALO’s Dangerous Target Alerts highlight range, graphical bearing, and heading of other vessels relative to yours. Meanwhile, VelocityTrackTM uses Doppler technology to show targets color-coded so you can identify potential threats at a glance. Because, when it comes to safety, situational awareness is everything.

The next generation of pulse compression radars, HALO 2000 and 3000 build on the features that have made HALO an established choice for boaters across the globe. The solid-state technology gets you up and running quickly, and HALO’s low-power pulsed transmissions make it safe to run in harbors and marinas. Dual Range mode allows you to keep an eye on distant weather cells while monitoring channel markers and high-speed watercraft up close. Advanced digital signal processing gives you a clearer view of targets, helping eliminate sea clutter, while Beam Sharpening provides enhanced separation between small or distant targets. Finally, HALO 2000 and 3000 have the same footprint as their predecessors, making it easy to upgrade your current system. It’s also compatible with a range of Simrad(R) chart plotters, including NSSTM, NSXTM, NSOTM, and GOTM.

Designed with an intuitive interface HALO arrays make operation easier with smart features like Harbour, Offshore, Bird, and Weather modes. These Preset Modes require no manual tuning - just select your chosen mode and go. This simple approach also extends to fishing, with HALO’s powerful bird-finding capability which enables boaters to find flocks of birds and - more importantly - schools of fish at a distance.
